Exceeds IS:446 type-18 BAR

Tube: Specially designated compound nitrile and other synthetic blend rubber.

Reinforcement: High tenacity synthetic textile braid

Cover: Specially designated for weather, abrasion & ageing resistance natural rubber, black.

Nominal I.D.		Mean O.D.		Max Working Pressure		Minimum Burst Pressure		Max Vacuum	Min. Bend Radius
INCH	MM	INCH	MM	BAR	PSI	BAR	PSI	HG	MM
1/4	6.3	0.51	12.8	18	255	56	800	25	76
5/16	8.0	058	14.8	18	255	56	800	25	102
3/8	10.0	0.66	16.8	18	255	56	800	25	102
1/2	12.5	0.81	20.5	18	255	56	800	25	120
3/4	20.0	1.12	28.5	18	255	56	800	25	150
1	25.0	1.42	36.0	18	255	56	800	15	200
1.1/4	31.5	1.69	43.0	18	255	56	800	15	250
1.1/2	38.0	1.97	50.0	18	255	56	800	10	300
2	50.0	2.50	64.0	18	255	56	800	10	419

Temperature Range:  -30^o C to +82^o C

 * 1” , 1  ¼” ,1  ½” & 2” – Double braid high tenacity synthetic yarn.
