Tube: Black, oil-resistant synthetic rubber

Reinforcement: Double braid high tensile steel wire

Cover: Blue colour, wrap finish synthetic rubber resistant to abrasion, weather, Oil and ozone

Application: High temperature and high-pressure cleaning professional equipment. Can be used in Air, Oil and Rig application

Operating Temperature Range: -40°C to +155°C

Hose I.D		Hose O.D	Working Pressure		Bursting Pressure		Bending Radius
MM	INCH	MM	BAR	PSI	BAR	PSI	MM
6.4	1/4	15.0	400	5800	1600	22840	100
9.5	3/8	19.0	330	4800	1320	18840	130
12.7	1/2	22.2	275	4000	1100	15720	180
15.9	5/8	25.4	250	3630	1000	14280	200
19.0	3/4	29.3	215	3120	850	12280	240
25.4	1	38.0	175	2500	650	9420	300
31.8	1-1/4	48.3	125	1820	500	7140	420
38.1	1-1/2	54.6	90	1310	360	5140	500
50.8	2	67.3	80	1160	320	4540	630
