Tube: Black colour, synthetic rubber resistant to oil and water

Reinforcement: Single braid high tensile steel wire

Cover: Black colour, wrap finish synthetic rubber resistant to abrasion, weather, Oil and ozone

Application: It can be used in petroleum, synthetic or water-based fluids in hydraulic systems. These hoses are also suitable for agriculture, earthmoving and material handling equipment and machineries

Temperature Range: Continuous: -40°C to +100°C (Intermittent: +120°C)

Hose I.D.		Hose O.D.	Working Pressure		Bursting Pressure		Bending Radius
MM	INCH	MM	BAR	PSI	BAR	PSI	MM
6.4	1/4	13.0	225	3260	900	13050	100
7.9	5/16	15.0	215	3120	860	12325	115
9.5	3/8	17.4	180	2610	720	10440	130
12.7	1/2	21.0	160	2320	640	9280	180
15.9	5/8	24.0	130	1885	520	7540	200
19.0	3/4	28.0	105	1520	420	6090	240
25.4	1	35.0	88	1280	352	5075	300
31.8	1-1/4	44.5	63	910	252	3650	420
38.1	1-1/2	51.3	50	725	200	2900	500
50.8	2	64.0	40	580	160	2320	630
63.5	2-1/2	74.0	40	580	160	2320	760
76.2	3	86.0	40	580	160	2320	900
